Shantui SD22E

Single ripper / Three-shank ripper

L×W×H (Ripper not included) 6000×3725×3332.18mm Operating weight (Ripper not included) 24.6t Engine Cummins NT855-C280S10 Rated power 162/1800 kW/rpm Gradeability 30° Blade type Straight tilt blade U-blade Angle blade Blade width Straight tilt blade 3725×1315mm U blade 3800×1343mm Angle blade 4365×1055mm Dozing capacity Straight tilt blade 6.4m3 U blade 7.5m3 Angle blade 4.7m3 Ma× drop below ground of blade 538mm Lift height of blade 1210mm Ripper type Single ripper Three-shank ripper Ripping depth of ripper Single ripper 695mm Three-shank ripper 666mm Lifting height of ripper Single ripper 515mm Three-shank ripper 555mm Number of carriers (each side) 2     Number of track rollers (each side) 7 Number of track shoes (each side) 41 Width of track shoe 560mm Track gauge 2000mm Ground length and ground pressure 3050-0.072mm/MPa Pitch 216mm Forward speed 0–3.6km/h 0–6.5km/h 0–11.2km/h Reverse speed 0–4.3km/h 0–7.7km/h 0–13.2km/h
