Hitachi ZX 200
Preço sem IVA
Imprimir
INFO
Grupo de produtos
Escavadoras de rastos
Marca / modelo
Hitachi ZX 200
Ano de fabrico
2024
Horas de utilização
500 h
País
China
Grau geral
1
2
3
4
5
Mascus ID
7A5D8895
PREÇO
Escolher moeda
DETALHES
N°. de ref. de armazém
1
Tipo de accionamento
Diesel
Número de série
1
Número de proprietários anteriores
1
Última inspecção
2025-07-02
Condição do chassi
Good Condition
Motor
Original
Peso bruto
20 300 kg
Potência do motor
122 kW (166 cv)
Fabricante do Motor
Original
Matrícula
1
Classe de emissão
Stage V
Capacidade do balde
0,80 m3
Largura Rastro
600 mm
Velocidade máxima
5,50 km/h
Dimensőes em transporte (CxLxA)
9520 x 2860 x 3010 mm
Cor Original
Original
Dipper / stick length
2 910 mm
Informações sobre a condição/garantia
1 Year
País de fabrico
Japão
Condições de entrega
FCA, FOB, CIF, EXW
Certificados
EPA, CE
Acessórios
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Acessórios
valvula de segurança de braço
valvula de segurança da lança
caixa fios twig
Ar condicionado
Hidráulica adicional
Pré-filtro motor
Balde de esqueleto
Disjuntor Bateria
Farol Luz Rotativa
Aquecedor Gasóleo
Controlo por Joystick
Balde Escavação Standard
Cable bucket
Ditching/grading bucket
V ditch bucket
Outras informaçőes
Parameter configuration of Hitachi ZX200 excavator
Specification
The overall working weight of the machine (kg) is 20,300
Bucket capacity (m³) : 0.8
Boom length (mm)5.68 (H-type)
Boom length (mm)2.91 (H-type)
Origin: Japan
Tonnage (tons)20
Power Traditional Power
Bucket backhoe
Joint venture/import by manufacturers
Power Traditional Power
Performance
Rotational speed (rpm) : 13.3
Walking speed (km/h) : 3.5/5.5
Climbing ability (%)70/35°
Ground specific pressure (Kpa) : 45
Bucket digging force (kN)151
The digging force of the boom (kN) is 109
Power system
Engine model: ISUZU ISuzu AI-4HK1X
Rated power (kw/rpm)122/2000
Displacement (L)5.193
Number of cylinders (4)
The cooling method is water cooling
The working mode is direct injection, turbocharging, with intercooler
Hydraulic system
Main pump type variables: 2 plunger pumps + 1 gear pump
The main overflow set pressure (Mpa) is 34.3
Walking hydraulic motor type: Variable piston pump ×2
Rotary hydraulic motor type: quantitative plunger pump ×1
Working hydraulic circuit (Mpa)34.3
Walking hydraulic circuit (Mpa)34.3
Rotary hydraulic circuit (Mpa)32.4
Pilot oil circuit (MPa)3.9
Is the hydraulic crushing pipeline standard? No
Oil capacity
Fuel tank (L)400
Hydraulic oil tank (L)135(full tank 200)
Engine oil change volume (L)23
Main body size
The total transportation length (mm) is 9520
The total transportation width (mm) is 2860
Total transportation height (mm) : 3010
The total height of the cab (mm) is 2950
The ground clearance of the counterweight (mm) is 1030
Track grounding length (mm)3370
The total length of the track (mm) is 4170
Track plate width (mm) : 600
The total width of the tracks (mm) is 2800
Track gauge (mm) : 2200
Minimum ground clearance (mm) : 450
Rear end turning radius (mm) : 2750
Scope of work
Maximum excavation radius (mm) : 9920
Maximum excavation depth (mm) : 6670
Maximum excavation height (mm) : 10040
Maximum unloading height (mm) : 7180
The maximum vertical excavation depth (mm) is 5990
Lifting or deepening with a bulldozer (mm) without a bulldozer
